Montagemethode | niet gespoeld |
Detectieafstand | 40mm |
betrouwbare detectieafstand | 0...36,2mm |
DC 3-draad/DC 4-draad | Npn | Nee | NBN40-L2-E0-V1 |
nC | NBN40-L2-E1-V1 |
geen + nc | NBN40-L2-A0-V1 |
PNP | Nee | NBN40-L2-E2-V1 |
nC | NBN40-L2-E3-V1 |
| geen + nc | NBN40-L2-A2-V1 |
dc 2-draad | Nee | NBN40-L2-Z0-V1 |
nC | NBN40-L2-Z1-V1 |
ac 2-draad | Nee | NBN40-L2-U0-V1 |
nC | NBN40-L2-US-V1 |
Bedrijfsspanning | 10 ... 30 V DC |
Schakelfrequentie | 0 ... 440 Hz |
Hysteresis | typ. 5 % |
omgekeerde polariteitsbescherming | omkering van de pool beschermd |
Kortsluitbeveiliging | pulsender |
Spanningsverlies | ≤ 2 V |
werkstroom | 0 ... 200 mA |
Uitstaatstroom | 0 ... 0,5 mA |
Leegloopvoedingsstroom | ≤ 20 mA |
Tijdvertraging voor beschikbaarheid | 80 ms |
Bedrijfsspanningsindicator | LED, groen |
Schakelstatusindicator | LED, geel |
MTTFd | 1510 a |
Missieperiode (TM) | 20 a |
Diagnostische Coverage (DC) | 0% |
Geëvalueerde Isoleringsspanning | 253 V |
Genormeerde Impuls Weerstandsspanning | 4000 V |
Omgevings temperatuur | 25 ... 85 °C |
Opslagtemperatuur | -40 ... 85 °C |
verbindingstype | Connectorplug M12 x 1 , 4-pins/schroefaansluitingen |
Massa | 130 g |
